GBOX Chemi-XX9, Gel Documentation System,230V/50Hz
د.إ 134,546.00
15 people are viewing this right now
Available on backorder
Description
About the brand
Reviews (0)
Questions
Description
9MP, 16bit camera system with motor driven fixed lens f0.95 with motor driven sample racking system. With 7 position motor driven filter wheel. Max image size 32.3 x 25.6cm. Includes EPI LED white lights and wiring for edge lightung unit (optional). With Genesys software and unlimited copies of GeneTools. No transilluminator or white light converter supplied. PC required (not included)
Specifications
| SYSTEM | G:BOX CHEMI XX6 |
G:BOX CHEMI XX9 |
| Image resolution (pixels m) | 6 | 9 |
| Effective resolution (pixels m) | 18 | 27 |
| A/D | 16 bit | 16 bit |
| Greyscales | 65,536 | 65,536 |
| Dynamic range OD | 4.8 | 4.8 |
| Quantum efficiency @ 425nm | 73% | 73% |
| Lens (motor driven) | F0.80 or F0.95 | F0.80 or F0.95 |
| Stage | Moving | Moving |
| Filter wheel (7 position motor driven) | All fluorescence applications | All fluorescence applications |
| UV filter | Yes | Yes |
| Use with external PC | Yes | Yes |
| DIMENSIONS | G:BOX CHEMI XX6 | G:BOX CHEMI XX9 |
| Max image area (cm) | 34.5×27.6 or 32.3×25.6 | 34.5×27.6 or 32.3×25.6 |
| Min image area (cm) | 15.6×12.5 or 15×11.8 | 15.6×12.5 or 15×11.8 |
| WxHxD (cm) | 57x99x55 | 57x99x55 |
| Weight (kg) | Approx. 45 | Approx. 45 |
| Power Input (V) | 100-240 | 100-240 |
| LIGHTING | G:BOX CHEMI XX6 | G:BOX CHEMI XX9 |
| Epi LED White Lights | Yes | Yes |
| HiLED (Red, Blue, Green) | Optional | Optional |
| HiLED (Red, Infrared) | Optional | Optional |
| HiLED (Red, Blue, Green, Infrared) | Optional | Optional |
| Visible Light Converter | Optional | Optional |
| Blue Converter Screen | Optional | Optional |
| Slide-out UV Transilluminator 302nm (20cm x 20cm) | Optional | Optional |
| Edge Lighting Unit | Optional | Optional |
Our software is compatible with Windows 11*
*In-house testing has revealed no issues with the current version of Windows 11 (22H2 Update Version 22621.1702)
Syngene
Syngene is a world-leading supplier of gel documentation (gel doc) systems for rapid, accurate imaging and analysis of fluorescence and visible gels, multiplexed fluorescence westerns, stain-free gels and chemiluminescent blots.
With over 30 years’ experience, our products are used globally by thousands of molecular biologists and scientists, who are successfully contributing accurate data to important projects in many of the world’s top academic research institutes and pharmaceutical companies. Our products are used in Life Sciences, Genomics and Proteomics applications.
